Home Automation IOT Printed Circuit Board Assembly with Gerber File and BOM List
♦ What is BOM List?
A BOM List (Bill of Materials list) is a structured document that enumerates every component, raw material, sub-assembly, fastener, adhesive, label, etc. required to build one complete unit of a product. For each line item it normally specifies reference designator(s), manufacturer part number, approved alternates, package type, value/tolerance, quantity per board or per product, procurement status and sometimes cost and lead-time. In electronics manufacturing the BOM list is the master recipe that purchasing, SMT programming, kitting, IQC, costing and logistics all follow; without an accurate BOM list a PCBA cannot be quoted, built, tested or repaired correctly.
♦ What is IoT Printed Circuit Board?
An IoT Printed Circuit Board (IoT PCB) is a compact, ultra-low-power circuit board specifically engineered to be the hardware core of an Internet-of-Things device. It integrates:
-
Micro-controllers / SoCs for local processing
-
MEMS sensors (temperature, humidity, motion, ambient-light, gas, etc.)
-
Wireless connectivity modules (Wi-Fi, BLE, Zigbee, LoRa, NB-IoT, LTE-M)
-
Efficient PMICs, DC-DC converters, coin-cell or energy-harvesting inputs
-
Antennas, matching networks and high-frequency controlled-impedance traces
Design priorities are miniature footprint (down to 10 mm × 10 mm), multi-year battery life, robust RF performance, and reliable operation in harsh or wearable environments. To meet these goals IoT PCBs frequently use high-density interconnect (HDI), rigid-flex or fully flexible substrates, ultra-thin FR-4 or polyimide dielectrics, and embed passives or even antennas in the inner layers. The finished board is the physical platform that lets the device sense, compute, store and securely transmit data to cloud or edge servers, forming the backbone of smart-home, industrial, medical and agricultural IoT application.
♦ Types of PCB Assembly Services:
-
- Turnkey PCB Assembly: Full service (PCB fabrication + component sourcing + assembly).
- Partial (Consignment) Assembly: Customer provides components; the assembler handles soldering.
- Prototype Assembly: Low-volume assembly for testing designs.
- High-Volume Production: Mass production for commercial devices.
DQS Electronic Group is one of the leading EMS company in China, we provide PCB design, PCB manufacturing, PCB assembly service and testing. Welcome send us your Gerber file to get free quotation. Our email: info@dqspcba.com
♦ Technical Parameters
| PCB Assembly Capability |
| Item | Normal | Special |
| SMT Assembly | PCB(used for SMT) specification | Length and Width( L* W) | Minimum | L≥3mm, W≥3mm | L＜2mm |
| Maximum | L≤800mm, W≤460mm | L ＞ 1200mm, W＞500mm |
| Thickness( T) | Thinnest | 0.2mm | T＜0.1mm |
| Thickest | 4 mm | T＞4.5mm |
| SMT components specification | Outline Dimension | Min size | 0201(0.6mm*0.3mm) | 01005(0.3mm*0.2mm) |
| Max size | 200 * 125 | 200 * 125 |
| component thickness | T≤15mm | 6.5mm＜T≤15mm |
| QFP,SOP,SOJ (multi pins) | Min pin space | 0.4mm | 0.3mm≤Pitch＜0.4mm |
| CSP/ BGA | Min ball space | 0.5mm | 0.3mm≤Pitch＜0.5mm |
| DIP Assembly | PCB specification | Length and Width( L* W) | Minimum | L≥50mm, W≥30mm | L＜50mm |
| Maximum | L≤1200mm, W≤450mm | L≥1200mm, W≥500mm |
| Thickness( T) | Thinnest | 0.8mm | T＜0.8mm |
| Thickest | 3.5mm | T＞2mm |
♦ Application Fields
♦ Advantages of DQS Team
- On-time Delivery:
-
- Owned PCBA factories 15,000 ㎡
- 13 fully automatic SMT lines
- 4 DIP assembly lines
2. Quality Guaranteed:
-
- IATF, ISO, IPC, UL standards
- Online SPI, AOI, X-Ray Inspection
- The qualified rate of products reach 99.9%
3. Premium Service:
-
- 24H reply your inquiry
- Perfect after-sales service system
- From prototype to mass production
